Summary ​
WVL3 (WorldView-Legion Camera) is an operational multispectral instrument operated by Vantor on WorldView Legion-3. It is associated with a satellite platform and has private data availability.
NOTE
The nominal band intervals and nadir ground sample distances follow the current Vantor WorldView Legion datasheet at 518 km altitude, which supersedes prelaunch values quoted for a 450 km orbit. Band identifiers use the channel names published in the datasheet, with separators normalized to underscores. No authoritative tabular spectral response samples were found.
Quick Facts
Instrument idWVL3
NameWorldView-Legion Camera
AcronymWVL
Typemultispectral
Platform typesatellite
PlatformWorldView Legion-3
OperatorVantor
Start date2024-08-15
Statusoperational
Availabilityprivate
Spectral Characteristics
Total bands9
Wavelength range425-832.5 nm
Bandwidth range20-350 nm
Ground sampling distance0.34-1.36 m
Spectral response functionNot available
Imaging
Swath Width10
Explore it with xeo ​
python
import xeo
instrument = xeo.instruments.WVL3
# Extract metadata
metadata = {
"id": instrument.id,
"name": instrument.name,
"acronym": instrument.acronym,
"type": instrument.type,
"platform_type": instrument.platform_type,
"platform": instrument.platform,
"operator": instrument.operator,
"start_date": instrument.start_date,
"end_date": instrument.end_date,
"status": instrument.status,
"availability": instrument.availability,
}
# Get the bands as a pandas DataFrame (returns None if it is not available)
instrument.bands()
# Get the Spectral Response Function as a pandas DataFrame (returns None if it is not available)
instrument.srf()
# Check the available extensions
print(instrument.extension_names)
for name, extension in instrument.extensions.items():
print(name, "->", list(extension))
